优存科技提供高质量，创新和性能驱动的产品，非常适合从计算，消费类，网络和工业到移动，嵌入式，汽车和物联网（IoT）的各种应用。
SPI Nor Flash 产品组合
2.5/3V 系列
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25HD10 | 1Mb | 2.3~3.6V | 120MHz(x1,x2) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25HD20 | 2Mb | 2.3~3.6V | 104MHz(x1,x2) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25HQ40 | 4Mb | 2.3~3.6V | 104MHz(x1,x2,x4) | SOP8 150mil USON8 2*3mm Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
|
| UC25HD40IB | 4Mb | 2.3~3.6V | 104MHz(x1,x2) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25HQ80 | 8Mb | 2.3~3.6V | 104MHz(x1,x2,x4) | SOP8 150mil USON8 2*3mm WLCSP Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
|
| UC25HQ80IB | 8Mb | 2.3~3.6V | 104MHz(x1,x2,x4) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25HQ16 | 16Mb | 2.3~3.6V | 133MHz(x1,x2,x4,QPI) | SOP8 150mil SOP8 208mil USON8 2*3mm Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25HQ32 | 32Mb | 2.3~3.6V | 104MHz(x1,x2,x4,QPI) | SOP8 150mil SOP8 208mil USON8 2*3mm Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25HQ64 | 64Mb | 2.3~3.6V | 104MHz(x1,x2,x4,QPI) | SOP8 208mil WSON 6*5mm Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
|
| UC25IQ64 | 64Mb | 2.7~3.6V | 133MHz(x1,x2,x4,QPI,DTR) | SOP8 208mil WSON 6*5mm WSON 8*6mm SOP16 300mil Known good die |
工业级 (I) -40℃ to +85℃ | 开发中 |
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25IQ128 | 128Mb | 2.7~3.6V | 133MHz(x1,x2,x4,QPI,DTR) | SOP8 208mil WSON 6*5mm WSON 8*6mm SOP16 300mil |
工业级 (I) -40℃ to +85℃ | 量产 |
|
1.8V 系列
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25LD10 | 1Mb | 1.65~2V | 100MHz(x1,x2) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25LD20 | 2Mb | 1.65~2V | 104MHz(x1,x2) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25LD40IB | 4Mb | 1.65~2V | 80MHz(x1,x2) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25LQ80 | 8Mb | 1.65~2V | 104MHz(x1,x2,x4) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 | ||
| UC25LQ80IB | 8Mb | 1.65~2V | 80MHz(x1,x2,x4) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25LQ16 | 16Mb | 1.65~2V | 133MHz(x1,x2,x4,QPI) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 样品 |
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25LQ32 | 32Mb | 1.65~2V | 104MHz(x1,x2,x4,QPI) | SOP8 150mil SOP8 208mil USON8 2*3mm WSON 6*5mm Known good die |
工业级 (I) -40℃ to +85℃ | 样品 |
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25LQ64 | 64Mb | 1.65~2V | 104MHz(x1,x2,x4,QPI) | SOP8 208mil WSON 6*5mm Known good die |
工业级 (I) -40℃ to +85℃ | 样品 |
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25LQ512 | 512Mb | 1.65~2V | 166MHz(x1,x2,x4,QPI,DTR) | WSON 8*6mm SOP16 300mil BGA24 8*6mm |
工业级+ (J) -40℃ to +105℃ | 开发中 |
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25LQ1G | 1Gb | 1.65~2V | 166MHz(x1,x2,x4,QPI,DTR) | SOP16 300mil BGA24 8*6mm |
工业级+ (J) -40℃ to +105℃ | 开发中 |
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25LQ2G | 2Gb | 1.65~2V | 166MHz(x1,x2,x4,QPI,DTR) | SOP16 300mil BGA24 8*6mm |
工业级+ (J) -40℃ to +105℃ | 开发中 |
宽压 系列
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25WD10 | 1Mb | 1.65~3.6V | 120MHz(x1,x2) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25WD20 | 2Mb | 1.65~3.6V | 104MHz(x1,x2) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25WD40IB | 4Mb | 1.65~3.6V | 104MHz(x1,x2) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25WQ80 | 8Mb | 1.65~3.6V | 104MHz(x1,x2,x4) | SOP8 150mil USON8 2*3mm Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
|
| UC25WQ80IB | 8Mb | 1.65~3.6V | 104MHz(x1,x2,x4) | SOP8 150mil USON8 2*3mm TSSOP8 Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25WQ16 | 16Mb | 1.65~3.6V | 133MHz(x1,x2,x4) | SOP8 150mil USON8 2*3mm Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25WQ32 | 32Mb | 1.65~3.6V | 104MHz(x1,x2,x4) | SOP8 150mil USON8 2*3mm TSSOP8 WSON 6*5mm Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
| Part No. | Density | Vcc | Frequency, MHz (Bus Width) | Key Features | Packages | Temperature Range | Status | Datasheet |
|---|---|---|---|---|---|---|---|---|
| UC25WQ64 | 64Mb | 1.65~3.6V | 104MHz(x1,x2,x4) | SOP8 208mil WSON 6*5mm Known good die |
工业级 (I) -40℃ to +85℃ | 量产 |
|
